NOVATOP FORM
Three-layer formwork panel
The premium NOVATOP FORM formwork panel combines high durability, stability and easy handling.
NOVATOP FORM formwork panel uses all the advantages of NOVATOP multilayer panels. Thanks to modern production technology, it is dimensionally stable, robust and capable of bearing loads in both directions. It stands out for its resistance to water and harsh weather conditions. Its low weight enables easy handling. It is also suitable for demanding classes of visual concrete. The melamine film guarantees a smooth surface, quick cleaning and a long service life with repeated use.
.
ASSORTMENT
Wood: Local spruce
Quality: Repairs on both sides
Thickness (mm): 21 (6-9-6), 27 (6-15-6), 27 (9-9-9)
Formats:
Width (mm): 500, 1,000, 2,000
Lengths (mm): 1,000, 1,500, 2,000, 2,500, 5,000
Surface treatment: Melamine resin, yellow colour
Surface treatment of edges Water-soluble varnish with high watertightness based on acrylic and alkyd resins,yellow colour
.
Why NOVATOP quality?
• The basis of all products is formed by a 3-layer NOVATOP panel
• Above-standard formats in lengths of up to 5 x 2.1 m
• Glued and repaired middle layers – enhance rigidity and reliability when used repeatedly.
• High-quality surface layers with side down pressure during pressing – guarantee up to twice the bending strength compared to conventional formwork panels
• Stability in both directions – retains its shape even under high loads
• Resistance to water and harsh weather conditions – no concerns even when used outdoors
• Low weight – quick assembly/disassembly and easier handling on site
• Melamine surface – smooth surface, quick cleaning and repeated use
• Output inspection of each panel is performed personally.
APPLICATION
For formwork of foundations, walls, columns, ceilings, staircases and more complex architectural elements. Also suitable for demanding classes of visual concrete and repeated formwork assemblies.
